McIntosh MXA70

Dynamic Headroom1.6dB Frequency Response+0, -0.5dB from 20Hz to 20,000Hz +0, -3dB from 10Hz to 100,000Hz Headphone Impedance20-300 ohms Input ImpedanceInput 1: 20K ohms unbalanced Input 2: 20K ohms balanced Intermodulation Distortion0.05% maximum, if the instantaneous peak power output is 150 watts or less per channel with both channels operating for any combination of frequencies from 20Hz to 20,000Hz Main/Sub Output1.2V for rated input (4V Maximum) Main/Sub Output Impedance500 ohms Maximum Input SignalInput 1: 4V Input 2: 8V Output Load Impedance8 ohms Power GuardLess than 2% THD with up to 12dB overdrive at 1,000Hz Power Output75 watts into an 8 ohm load is the minimum sine wave continuous average power output, both channels operating Rated Power Band20Hz to 20,000Hz Sensitivity (for rated output)Input 1: 300mV unbalanced Input 2: 600mV balanced Signal To Noise Ratio (A-Weighted)CD, Input1, Input 2: 98dB below rated output Tone Controls (Bass and Treble)Bass ±10dB (in 1dB steps) at 70Hz Treble ±10dB (in 1dB steps) at 10kHz Total Harmonic Distortion0.05% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz Voltage GainInput 1 and 2 to Main Output: 12dB Power Amplifier: 26dB Wide Band Damping FactorGreater than 100 FM Tuner Specifications 50dB Quieting Sensitivity1.5uV (14.8dBf) Antenna Input75 Ohms, Type “F” Coax connector Channel Selectivity60dB Adjacent Channel 66dB Alternate Channel Frequency Response±1dB 20 to 15,000Hz Harmonic DistortionMono: 0.4% Stereo: 0.8% Signal To Noise RatioMono: 70dB Stereo: 68dB Stereo Separation38dB Tuning Range87.5Mhz - 108.0Mhz (Europe) 87.9Mhz - 107.9Mhz (USA) 76Mhz - 90Mhz (Japan) Useable Sensitivity2.2uV (18.1dBf) AM Tuner Specifications Antenna InputRAA2 (supplied), Type “RJ45” connector Frequency Response0dB, -6dB 50Hz to 3,000Hz Harmonic Distortion0.5% Selectivity45dB Adjacent Channel Sensitivity350uV/m Signal To Noise Ratio50dB Tuning Range522khz - 1602khz (Europe) 530khz - 1710khz (USA) 522khz - 1611khz (Japan) SACD/CD Player Specifications Channel SeparationBetter than 98dB (1,000Hz) Disc FormatsSACD, CD, MP3 and WMA Dynamic RangeBetter than 100dB TransportLaser Type: Twin Beam Laser Beam Wavelength:650nm (SACD)/790nm (CD) Laser Power: CLASS IIa/CLASS I Loudspeaker Specifications Crossover Frequency2,000Hz Finish EnclosureHigh Gloss Black Finish GrilleBlack Knit Cloth Frequency Response60Hz - 45kHz Impedance8 ohms Nominal Power Handling75 Watts Sensitivity80dB (2.83V/1m equivalent) System Driver ComplementOne 4 inch Woofer/Midrange One 3/4 inch Dome Tweeter Features Power Requirement100V ~ 50/60Hz at 3.0 Amps 110V ~ 50/60Hz at 2.5 Amps 120V ~ 50/60Hz at 2.5 Amps 220V ~ 50/60Hz at 1.5 Amps 230V ~ 50/60Hz at 1.3 Amps 240V ~ 50/60Hz at 1.3 Amps Standby: Less than 0.5 watt Note: Refer to the rear panel of the MXA60 for the correct voltage. System Overall DimensionsWidth is 22 inches (55.88cm) Height is 10-7/8 inches (27.62cm) Depth is 16 inches (40.64cm) including connectors Note: When the Disc Player Tray is opened, the panel clearance required in front of mounting panel is 6-3/4 inches (17.2cm). System Shipping Carton DimensionsWidth is 35 inches (88.9cm) Depth is 20 inches (50.8cm) Height is 15-1/2 inches (39.4cm) System Weight64 pounds (29.03 Kg) net, 80 pounds (36.28 Kg) in shipping carton Downloads & Updates McIntosh President Charlie Randall talks about the MXA60 on Fox Business (13.17 MB) (3/30/2011) Download Manuals & Documents MXA60 Integrated Audio System Literature (1.50 MB) (5/31/2011) Download EXCITE award logo 10.09Audio Review 2.10 Italy (0.35 MB)DownloadAV Mentor Review 11.09 Greece (0.76 MB)Download
