Gryphon DAC One

• True Dual Mono Class A Analog configuration

• Zero negative feedback
• Sabre ES9018 High-End D/A converter
• USB input compatible with following audio formats via PC/MAC/Linux:
PCM: 44.1, 48, 88.2, 96, 176.4, 192, 352.8 and 384 kHz, up to 32 bits
DSD via USB: DSD64 (2.822MHz), DSD128 (3.072MHz), DSD256*
(5.644MHz) and DSD512* (6.144MHz)
• XLR, BNC and TOSLINK inputs compatible with PCM: 22.05, 24, 32, 44.1, 48, 64,
88.2, 96, 176.4 and 192 kHz, up to 24 bits
• User-selectable PCM and DSD digital roll-off filters
• Temperature-compensated, ultra-low jitter crystal oscillator with better than 5 parts
per million accuracy
• Super-Capacitor (12.5 Farad!) power supply for USB module - acts like a true
battery supply
• First-order PCM analogue filters and second-order DSD analogue filters with
silvered Mica and Polypropylene capacitors
• Analogue output stages with discrete, ultra-low noise +/- 22VDC regulated voltage
supplies for best analogue THD and noise suppression
• Multiple Local Voltage regulators for best digital noise suppression
• Discrete, separate left/right channel ultra-low noise power supply for analogue
section of ES9018 DAC
• Ultra-short signal path
• Minimal internal wiring
• Two four-layer printed circuit boards up to 70my copper
• PCB-mounted sockets eliminate wiring and shorten signal path
• Gold-plated Swiss Neutric XLR socket for one balanced 110
AES source
• Gold-plated 75
BNC sockets with Teflon insulation for 2 S/PDIF sources
• One TOSLINK optical fiber input
• Designed and built in Denmark
*(at the moment, DSD256 and DSD512 only on Windows systems)
Specifications can be changed by Gryphon Audio Designs without further notice.
