Fiche technique
Informations techniques complémentaires
- Playback formats:
- Playback of media from:
- standard DVD-Video/CD-Audio
- CD-R / RW
- DVD-R / RW
- DVD+R / RW
- MP3 Playback:
- Multi Session CD-R/RW, variable data rate
- WMA files compatibility with DVD and CD players.
- JPEG / Kodak Picture CD
- VCD / S-VCD
- DivX Video-Playback (New Video Compression Format) (Version 3.11, 4.xx, 5.xx, 6.xx, VOD), DivX (R) Certified
- Playback of media from:
- Construction:
- Mechanical Construction: 1 Chamber, 1 section
- Top cover: 1 layer
- Bottom: 1 layer
- DVD Drive: DENON-Standard
- Buffer Memory for reducing layer change: 2 MB
- Double Speed Drive System
- Video Section:
- HDMI-output (HDCP) (Version 1.1)
- Scaler (for DVI, HDMI) 480p or 576p / 720p / 1080i/p, (50, 60 Hz)
- Progressive Scan: PAL / NTSC
- Selectable Progressive Mode (Auto1, Auto2, Video)
- Progressive ScanEngine: Matsushita
- Video D/A Converter: 12 Bit, 108 MHz
- Video Oversampling interlaced / progressive: x 8 / x 8
- Video Equalizer: 5 parameters
- Optimum Black Level Adjustment
- Squeeze Mode for DVI/HDMI
- NTSC Playback
- NTSC/PAL Conversion
- RGB Output via SCART
- Audio Section:
- 2 Channel Downmix Ability (discrete 2CH Audio Output) 192 kHz / 24-Bit (Burr-Brown PCM1782)
- Audio D/A Converter 2CH
- Dolby Digital / DTS Decoder: Downmix / -
- Virtual-Surround (VSS Virtual Surround Sound)
- Features:
- Zoom: x2, x4
- Dynamic Compression
- Resume
- Automatic Power off
- DVD Parental Control
- Camera Angle Selection
- Display Dimmer: 4 steps incl. off
- Remote Control: RC-1018
- Playback Features:
- Manual search / track search
- Direct track selection / chapter selection
- Repeat: Track/Chapter, Disc, A-B
- Random playback
- Slow motion forward / back: 1/2-1/16 / 1/2-1/16, 3 steps / 3 steps
- Quick motion forward / back: 2x-100x / 2x-100x, 5 steps / 5 steps
- Programmed playback: 99 tracks/chapters
- Connectors:
- HDMI-output (HDCP) (Version 1.1)
- Digital Video (HDCP)
- Digital Audio (2CH / 6CH)
- Colour Component Output
- S Video Output
- Composite Video Output
- SCART (RGB, Composite)
- Digital Output optical / coaxial: 1 / 1
- Digital Output 96-kHz
- Analogue Audio Output (Stereo)
- HDMI-output (HDCP) (Version 1.1)
- General:
- Dimensions (W x H x D mm): 435x75x310
- Weight: 2,3 kg
- Standby Power Consumption: < 1 Watt
