Fiche technique
Informations techniques complémentaires
•6 digital inputs (USB, XLR AES/EBU, RCA Coaxial or BNC, RCA Coaxial, Toslink, 3.5mm Optical*):
•Transformer or optical isolated, AC coupled.
•Maximum bit depth: 24 bit
•Maximum S/PDIF sample rate: 192kHz
•Maximum USB sample rate: 44.1, 48, 96 kHz
•A small plugged-in USB module allows for future upgradeability to a higher-bit-rate USB interface card.
•Coaxial or BNC S/PDIF input: Only one of these inputs can be used when Input 3 is selected. To achieve optimum performance, we recommend a 75-ohm BNC cable (available from NuForce) with a BNC connector.
•On the front panel, a 3.5mm optical S/PDIF input.
•Outputs: XLR, RCA, 3.5mm and 6.3mm headphone output*.
•Output Impedance: RCA, 0.01 Ohm; XLR, 50 Ohm; Headphone, 10 Ohm
•Output voltage 0dB, 1kHz: RCA 2.0/4.0Vrms, XLR 4.0/8.0Vrms (Low output/High output versions, low output version has to be custom ordered)
•Headphone power spec.:
•288mW rms @ 30 Ohm
•210mW rms @ 120 Ohm
•152mW rms @ 300 Ohm
•THD+N: 0.01, 0dB, 1kHz
•SNR: 103dB, 1kHz, A-weighted
•Frequency Response: 20-20kHz +/- 0.25dB
•The true-balanced XLR output produces twice the gain of the RCA output. The remote and front panel controls allow for fixed and variable voltages.
•Touch panel control
•Remote control: volume, input select, dim, mute
•Volume and sample rate display
•Power consumption: 9W
•AC voltage: 100V/110V/220V/230V
•Dimension: 215mm (w) x 400mm (d) x 60mm (h)
•Weight: 3.2Kg net, 4.5Kg shipped
•* The headphone output and optical input share the 3.5mm connector.
