Fiche technique
Informations techniques complémentaires
AMPLIFIER SECTION
FTC 200W
Full Disclosure Power (all channels driven simultaneously) 7 x 120W (20.8dBW)
IHF Dynamic Power
8 ohms : 230W
4 ohms : 320W
Total Harmonic Distortion at rated power (THD + N) <0.08%
IM distortion at rated power <0.08%
Damping Factor, 8 ohms >60
Input Sensitivity and Impedance 1.3V (ref. 8Ω, VOL at 0dB)
Frequency Response ±0.8dB (ref. 1kHz, 20Hz-20kHz)
Signal/Noise Ratio >93dB (ref. rated power at 8Ω, A-WTD)
>83dB (ref. 1W/8Ω, A-WTD)
PREAMPLIFIER SECTION
Frequency Response ±0.5dB (ref. 20Hz-20kHz)
Signal/Noise Ratio >-100dB (ref. 1W/8Ω, A-WTD)
Total Harmonic Distortion + Noise (THD + N) <0.01%
Input Sensitivity 330mV (ref. 2V)
Maximum Output Level >4V
TUNER SECTION
AM SECTION
Tuning Range 530kHz - 1710kHz (120V version, 10kHz steps)
531kHz - 1620kHz (230V version, 9kHz steps)
Usable Sensitivity 55dBμV
Signal/Noise Ratio 38dB
Total Harmonic Distortion <3%
Loop Sensitivity 20dB S/N 66dBμV
FM SECTION
Tuning range 87.50MHz - 108.50MHz
Usable Sensitivity Mono <9dBμV
Signal/Noise Ratio
Mono : 60dB
Stereo : 55dB
Total Harmonic Distortion
Mono : 0.7%
Stereo : 1.0%
Channel Separation 30dBμV
RDS Decode Sensitivity 28dBμV
GENERAL
Standby power <0.5W
Unit Dimension (WxHxD) - Gross (includes feet, knobs and terminals)
435 x 197 x 438mm
Net weight 25.2kg (55.6lb)
Shipping weight 29.2kg (64.4lb)
