Fiche technique
Informations techniques complémentaires
AMPLIFIER SECTION
FTC 7 x 110W
Full Disclosure Power (all channels driven simultaneously) 7 x 60W (0.05% THD, 20-20kHz)
IHF Dynamic Power
8 ohms : 137W
4 ohms : 243W
Total Harmonic Distortion at rated power <0.08%
IM distortion at rated power <0.08%
Damping Factor, 8 ohms >60
Input Sensitivity and Impedance 250mV/50kohms
Frequency Response ±0.8dB (ref. 1kHz, 20Hz-20kHz)
Signal/Noise Ratio >100dB (ref. rated power at 8 ohms, A-WTD)
>90dB (ref. 1W at 8ohms, A-WTD)
TUNER SECTION
AM SECTION
Tuning Range 530kHz - 1710kHz (120V version, 10kHz steps)
531kHz - 1620kHz (230V version, 9kHz steps)
Usable Sensitivity 30dBμV
Signal/Noise Ratio 38dB
Total Harmonic Distortion <3%
Loop Sensitivity 20dB S/N 66dBμV
FM SECTION
Tuning range 87.50MHz - 108.50MHz
Usable Sensitivity Mono <15dBμV
Signal/Noise Ratio
Mono : 60dB
Stereo : 55dB
Total Harmonic Distortion
Mono : 0.25%
Stereo : 0.5%
Channel Separation 40dB
RDS Decode Sensitivity 28dBμV
GENERAL
Idle Power 53W
Standby power <0.5W
Unit Dimension (WxHxD) - Gross (includes feet, knobs and terminals)
435 x 172 x 397mm
Net weight 15.4kg (33.9lb)
Shipping weight 18.0kg (39.6lb)
